Air Conditioner Solar Runtime Calculator – Battery Hours

How long can a battery run an air conditioner? Use this free air conditioner solar runtime calculator to estimate how many hours your AC can operate using stored battery energy. Calculate runtime based on battery capacity, air conditioner wattage, inverter efficiency and compressor duty cycle.

Whether you are powering a window air conditioner, portable AC, mini-split or RV air conditioner, this calculator helps estimate battery runtime for off-grid homes, cabins, campers and solar-powered systems.

Example: A 5kWh battery with 80% usable capacity provides approximately 4kWh before inverter losses. If an air conditioner averages 800W while operating, uses a 50% duty cycle and has 90% inverter efficiency, estimated runtime is approximately 9 hours, assuming no additional loads.

Simple Mode provides illustrative air-conditioner and battery assumptions. Advanced Mode allows more detailed calculations using measured electrical consumption, battery specifications and operating conditions.

Important: This calculator estimates battery-only runtime. It does not include incoming solar generation, predict room temperature or guarantee overnight cooling. Actual results depend on compressor cycling, temperature, insulation, equipment efficiency and battery condition. Inverter continuous power, startup surge and electrical compatibility must be verified separately.

Jump to the AC Runtime Calculator ↓ · Calculation Guide · Frequently Asked Questions · Methodology and Limitations

Air Conditioner Solar Runtime Calculator
AC Runtime · Battery Planner

How long will your battery keep the AC running?

Compare battery-only runtime scenarios using illustrative Simple-mode EER and duty assumptions or entered Advanced watts and duty. This is not a room-cooling simulation or a dependable prediction for a particular air conditioner.

8,000 BTU
AC Sized For
60%
Duty Cycle
EER 10
Efficiency assumption
2,400 W
Startup Surge
Planning note: AC runtime depends on real room heat gain, insulation, battery condition, inverter limits, compressor behavior, and weather. Use this as a sizing estimate and verify final inverter/battery setup before relying on it during an outage.
Quick Runtime Estimate
Battery Capacity
Battery Voltage optional Ah mode
Battery Ah optional Ah mode
Battery Health
Additional Reserve % of DoD-limited energy
Inverter Surge Rating W, for AC startup check
AC Type Affects duty cycle + efficiency
AC Size (BTU) Higher BTU = more watts
Outdoor Temperature 95°F
Live Runtime Estimate
Estimate, not a prediction: Simple mode uses default EER values and estimated duty cycles. These assumptions have not been validated for every unit or climate. Actual runtime depends on the air conditioner, temperature, humidity, insulation, thermostat setting and battery system. Use measured electrical consumption where possible. This is a scenario estimate, not a dependable prediction for an individual air conditioner; measured inputs do not guarantee runtime under changing conditions.
—
hours
Cooling
Battery usable—
Avg draw—
Peak surge—
Surge check—
Cooling rating (BTU/h)—
Room cool-down—
Detailed Results
Runtime Estimate
—
—
Usable AC-side stored energy
—
Load-side energy from the battery
Daily grid-energy equivalent
—
Illustrative 24h demand at $0.15/kWh
Illustrative temperature scenarios — Simple mode only
Mild (78°F)
—
—
Warm (85°F)
—
—
Hot (95°F)
—
—
Extreme (105°F)
—
—

Battery-only estimate: no incoming solar is included. Simple mode uses illustrative equipment and duty assumptions, not a room heat-load model. In Advanced mode, temperature and insulation do not change your entered duty. Running watts × duty must represent average AC consumption; include off-cycle fan/standby demand in Other Loads, or enter measured average watts with 100% duty. All loads are treated on the AC side of the entered inverter efficiency. Additional reserve is a percentage of the DoD-limited energy.

Battery Size vs AC Runtime — unchanged scenario assumptions
Battery SystemCapacityUsable WhRuntime
How we got this number

Enable JavaScript and enter your inputs to see the calculation and assumptions.

Planning from your entered values

Compare battery capacity, average load, and equipment limits using the calculator above.

How to use the air conditioner solar runtime calculator

  1. Enter nominal battery energy in the selected unit. Convert Ah to Wh using nominal battery voltage when needed; Ah alone does not specify stored energy.
  2. Choose battery chemistry, health and additional reserve assumptions. Chemistry presets are illustrative DoD fractions, not manufacturer-specific ratings.
  3. Use Simple mode for an approximate scenario based on cooling capacity and preset efficiency/duty assumptions. Those assumptions are not measurements of your AC.
  4. Use Advanced mode for measured running watts and duty cycle. If your measurement already represents average total AC power, enter it with 100% duty to avoid reducing it twice.
  5. Add concurrent loads and any fan or standby demand not already included in the measured AC figure. Keep all energy losses on the stated path and avoid double counting.
  6. Compare full running and startup demand with actual inverter specifications separately from the runtime calculation.

Battery-only AC runtime formula

Usable load-side Wh = nominal battery Wh × health × DoD × (1 − additional reserve) × inverter efficiency × (1 − additional loss).

Average load watts = AC running watts × duty fraction + other load watts.

Estimated elapsed runtime hours = usable load-side Wh ÷ average load watts. Duty cycle is already included in that elapsed-time estimate. Do not extend the result again on the basis that the compressor cycles.

Additional reserve here reduces the energy allowed by the DoD fraction. It is not another absolute state-of-charge cutoff. If your battery specification already includes a usable-energy limit, check that you are not applying the same reserve twice.

Simple versus Advanced power estimates

Simple mode estimates electrical watts from cooling capacity in BTU/h divided by a default EER, then applies estimated duty-cycle assumptions. These defaults have not been validated for every air conditioner or climate and should not be treated as individual performance predictions. Cooling capacity is not electrical power. Advanced mode uses the watts and duty you enter without applying another temperature multiplier.

The stated temperature and equipment options do not make this a room-cooling simulation. Insulation, heat gain, humidity, thermostat behavior and variable-speed operation can change actual demand. Measure energy over a representative period for a particular air conditioner. Measurements improve the inputs but do not guarantee the same runtime when conditions change.

Reading the air conditioner solar runtime calculator results

Calculated hours describe operating time under the entered average electrical demand. They do not establish that an inverter can start the compressor or that the battery can deliver the required current. A larger energy capacity can extend the modeled runtime while still leaving a power-limit problem unresolved.

Continuous inverter output should be compared with full AC running watts plus concurrent loads. Startup comparison uses startup demand plus concurrent loads, but actual surge duration, VA, waveform, output voltage and battery discharge limits remain equipment-specific. An unknown surge rating cannot be treated as a successful startup check.

How much battery capacity do I need to run an air conditioner?

Estimate the average electrical load first, then multiply by the hours of cooling you want. For an energy-only sizing scenario, nominal battery Wh = average load W × operating hours ÷ [health × DoD × (1 − reserve) × inverter efficiency × (1 − additional loss)]. This reverses the runtime equation; it does not check compressor startup or guarantee cooling performance.

For example, an AC drawing 750W while running at 60% duty, plus 120W of other loads, averages 570W. Six hours requires 3,420Wh delivered to those loads. With full health, 90% DoD, 10% additional reserve, 92% inverter efficiency and 8% other loss, the nominal battery requirement is about 4,988Wh, or 5.0kWh. Those are the same assumptions used in the reproducible example below.

Can I use this for a mini split, RV or portable air conditioner?

Yes, as a battery-energy scenario using the unit’s measured electrical demand in Advanced mode. Mini split and variable-speed loads can vary throughout the day; representative measured average watts with 100% duty are more useful than treating a cooling-capacity label as electrical watts. Include fan and standby demand only when it is not already included in your measurement. A battery runtime result does not determine solar-panel count. Continue with the Solar Array Planner to assess recharge separately.

Planning solar recharge separately

First estimate daily electrical energy under the intended operating pattern. Compare that with location- and season-specific solar production and charging constraints. The runtime calculation alone cannot establish how many panels are required or whether a battery will recharge before the next cooling period.

Continue with the Solar Array Planner for panel-capacity scenarios, the Battery Bank Size Calculator for storage and the Solar Inverter Size Calculator for a separate load-power scenario. Verify actual manufacturer limits before selecting equipment.

Reproducible Runtime Example

Advanced mode: 5,000Wh LiFePO4, full health, 10% additional reserve, 92% inverter efficiency, 8% other loss, 750W running power, 60% duty, and 120W other loads.

Usable energy = 5,000 × 0.90 × 0.90 × 0.92 × 0.92 = 3,427.92Wh. Average load = 750 × 0.60 + 120 = 570W. Runtime = 3,427.92 ÷ 570 = 6.01 hours. At 10,000Wh with every other input unchanged, runtime is 12.03 hours.

Air Conditioner Runtime: Questions and Assumptions

What does the calculator estimate?

A battery-only runtime scenario under the entered average electrical load. Simple-mode default EER and estimated duty assumptions have not been validated for every unit or climate. Results are estimates, not dependable predictions for an individual air conditioner. They do not predict room temperature, time to reach a thermostat setting, or solar-assisted runtime.

How do I use measured consumption?

In Advanced mode, enter measured average AC watts and set duty to 100%. Alternatively enter running watts and a measured duty fraction, then include fan or standby consumption during off periods in Other Loads. Do not apply duty a second time to a measurement that is already averaged.

How are watts estimated from BTU/h?

For the illustrative Simple-mode calculation, electrical watts = rated cooling BTU/h ÷ EER. The preset EER values are assumptions, not verified ratings for your appliance. SEER is a seasonal rating and should not be substituted as an instantaneous EER. U.S. Department of Energy explanation of EER and SEER.

Can the inverter start the AC?

Compare full running watts plus concurrent loads with continuous output capacity; compare startup watts plus concurrent loads with surge capacity. Watt ratings alone do not establish compatibility: surge duration, VA, output voltage and battery discharge limits also matter.

How much solar is needed?

Calculate daily energy use separately, then divide that energy by local peak sun hours and an overall performance ratio. The battery-only runtime result cannot establish a required solar array or guarantee overnight cooling.

Calculator methodology and limitations

Recommended Next Steps

Continue Planning After AC Runtime Estimation

After estimating how long your battery can run an air conditioner, the next step is to calculate storage requirements, evaluate other electrical loads, estimate battery recharge time and determine the solar panel capacity needed to support your energy consumption.

These calculators provide planning estimates. Actual equipment compatibility, electrical safety and cooling performance require separate verification.

Battery Bank Size Calculator

Estimate the battery storage capacity needed to operate your air conditioner and other appliances for your desired backup period.

Calculate Battery Capacity →

Solar Battery Runtime Calculator

Calculate how long your battery bank can support multiple electrical loads, including your air conditioner, refrigerator, lighting and other appliances.

Calculate Total Runtime →

Solar Battery Charge Time Calculator

Estimate how many equivalent charging hours and solar days your panels may need to recharge the battery after operating your air conditioner.

Estimate Recharge Time →

Solar Array Planner

Estimate the solar panel capacity needed to replenish daily air-conditioner energy consumption using your location’s peak sun hours and system-loss assumptions.

Plan Your Solar Array →

Important planning note: Battery runtime, solar production and charging time are separate calculations. A solar array that produces enough energy over an entire day does not necessarily provide enough instantaneous power to operate an air conditioner or recharge its battery reliably. Verify inverter continuous and surge ratings, battery discharge limits and electrical compatibility before selecting equipment.
