Battery Bank Size Calculator

Estimate nominal battery storage from daily energy use, backup days, depth of discharge and stated delivery-efficiency assumptions. Compare the calculated energy target with complete battery-module strings at your chosen nominal voltage.

This calculator provides a planning scenario, not an exact prediction or a guarantee of uninterrupted power. It does not approve equipment compatibility, current capability, wiring or charging design.

Jump to the battery bank size calculator · Read the assumptions and example · Methodology and limitations

Illustrated off-grid battery bank with solar charging and battery storage planning
Flagship Battery Planning Tool

Battery Bank Size Calculator

Plan a real off-grid battery bank with simple or advanced modes, chemistry-aware defaults, battery presets, voltage recommendations, and a planning dashboard that shows usable capacity, battery count, and layout.

What this calculates
Required storage, usable capacity, nominal bank size, battery count, and recommended voltage.
Real-world factors
Explicit DoD, battery-delivery and inverter-efficiency assumptions, plus an additional capacity margin.
Auto-save & share
Inputs may be saved locally in this browser and shared through a link containing the selected settings. Avoid sharing sensitive appliance names.

Simple Battery Bank Sizing

Shared-model estimate with daily AC energy, autonomy, editable DoD, combined delivery and capacity margin. Initial assumptions match System Size.

Example: 5,000 Wh = 5 kWh per day.
How many days the bank should last without charging.
Selecting chemistry loads an example DoD; the editable combined delivery factor includes battery/inverter/wiring losses once. Verify product limits.
Controls nominal Ah and complete-string rounding. Equipment voltage compatibility is not verified.
Enter the actual daily Wh for the selected loads; this choice does not apply an automatic reduction.

Advanced Battery Bank Planner

Build from real appliance loads, battery specs, and efficiency losses.

Use the battery/inverter manufacturer’s minimum operating input voltage to screen higher DC current. Blank uses nominal voltage only.
Use the manufacturer-rated continuous limit of one complete series string; this does not establish allowable series/parallel wiring or surge support.

Appliance Load Table

Add real loads with wattage, hours, quantity, and optional surge.

Running daily total: 0 Wh / day

Enter daily AC-side energy for the loads you actually intend to support. Critical-only selection is descriptive and applies no guessed reduction. Capacity margin adds to the nominal sizing target; it does not establish a cutoff reserve. Battery efficiency here is a discharge delivery factor, not round-trip charging efficiency. Voltages must follow the same nominal convention.

Results Dashboard

Battery Bank Plan

Run the calculator to generate required storage, battery count, voltage guidance, and planning notes.

Enter your inputs, then calculate to see a full battery bank plan.
Daily Load
—
Target Nominal Energy
—
Required Delivered Energy
—
Rounded Installed Energy
—
Target Ah Before Rounding
—
Battery Count
—
Configuration
—
Selected Nominal Voltage
—
Conceptual Battery Bank Layout — not a wiring diagram

Compare the unrounded Target Nominal Energy with System Size. Rounded Installed Energy can be larger because complete battery strings are required. Advanced mode combines battery discharge delivery × inverter efficiency; Simple mode enters that combined factor directly.

Continue this plan in System Size →

Helpful equipment

Equipment to Compare for Battery Bank Planning

These products are examples, not an automatically compatible battery bank configuration. Confirm chemistry, usable capacity, battery management limits, charging requirements, fusing and equipment ratings before purchase or installation.

LiTime LiFePO4 Deep-Cycle Battery

Compare nominal Ah and Wh ratings as you plan an appropriately sized battery bank.

Click for the latest price.

Victron SmartSolar MPPT 100/50 Controller

Compare charge-controller ratings against your proposed battery and solar array.

Click for the latest price.

Klein Tools CL390 Digital Clamp Meter

A measurement tool for electrical checks by someone trained to work safely.

Click for the latest price.

This section contains affiliate links. We may earn a commission.

What the battery bank size calculator estimates

The tool estimates nominal storage needed to deliver the entered daily AC energy for the selected backup period. It applies the stated DoD, battery-discharge delivery factor and inverter efficiency, then adds a separate capacity margin. Each factor is a planning assumption; actual usable energy depends on the battery and equipment.

Battery capacity formula

Required delivered Wh = daily AC Wh × backup days.

Target nominal Wh = required delivered Wh ÷ DoD fraction ÷ battery-delivery factor ÷ inverter efficiency × (1 + additional capacity-margin fraction).

Target Ah before module rounding = target nominal Wh ÷ nominal system voltage. The battery-delivery factor represents the discharge path in this model, not charging round-trip efficiency. Avoid counting the same loss in multiple inputs.

Capacity margin is not a state-of-charge reserve

A 20% capacity margin multiplies the calculated target by 1.20. It does not mean the battery stops at 20% state of charge, and it does not guarantee adequate storage through every outage or cloudy period. DoD and a capacity margin are separate assumptions.

Choose assumptions from your actual requirements and equipment documentation. Chemistry presets are illustrative rather than universal safe-discharge limits. Temperature, aging, operating voltage, discharge-rate effects and changing demand are not fully modeled.

Worked example with every factor stated

Assume 5,000Wh/day, two backup days, 90% DoD, 96% battery-discharge delivery, 94% inverter efficiency and 20% additional capacity margin.

  • Required delivered energy: 5,000 × 2 = 10,000Wh.
  • Target nominal storage: 10,000 ÷ 0.90 ÷ 0.96 ÷ 0.94 × 1.20 = approximately 14,775.41Wh, or 14.78kWh.
  • At 24V nominal, target Ah before rounding is approximately 615.64Ah.
  • With matching 12V 100Ah modules and a 24V target, each complete string contains two modules and stores 2,400 nominal Wh.
  • 14,775.41 ÷ 2,400 requires seven complete strings after rounding up: 2S7P, or 14 modules.
  • Rounded installed capacity is 24V, 700Ah and 16.8 nominal kWh.

Matching 24V 100Ah modules would instead need seven modules at the same nominal energy total. Module count therefore depends on module voltage and capacity, not just the target kWh. These examples explain arithmetic; they do not establish permission to connect a particular battery model.

How to read the results

Required delivered energy is the appliance-side demand for the selected backup period. Target nominal energy includes the entered discharge and efficiency factors plus margin. Rounded installed energy reflects complete strings. Target Ah is calculated before whole-module rounding, so it can differ from installed Ah.

Advanced mode also screens indicative battery-side current as peak running AC watts ÷ inverter conversion efficiency ÷ the selected DC operating voltage. The separate battery energy-delivery factor is not automatically applied to this instantaneous-current calculation. Optional manufacturer-rated per-string current can be compared with estimated continuous demand; this screening does not establish approved current sharing, surge capacity or wiring compatibility.

The module nominal voltage must divide the target nominal voltage into a whole-number series count. Incompatible ratios are rejected rather than rounded into a guessed wiring arrangement. The diagram is conceptual grouping only; it does not specify terminal polarity, cable routing or protection.

Using Simple and Advanced modes

Simple mode exposes allowed DoD and a single combined battery-to-AC-load delivery factor, including inverter losses once. Its initial 80% DoD, 90% delivery and 0% margin match System Size. Advanced mode retains separate delivery and inverter factors. Previously saved links preserve their original factors. Enter the daily energy you actually intend to supply; the load-category choice does not automatically reduce your energy figure.

Advanced mode supports an appliance list and explicit factors. Use representative daily hours and power measurements. Battery chemistry changes must not be treated as proof of inverter efficiency or current capability. Entered peak and surge values are information for planning; daily Wh alone cannot establish instantaneous power requirements.

What still needs separate verification

Use the exact battery and inverter manufacturers’ minimum operating-voltage, BMS continuous and surge-current ratings to check power capability. Inverter idle consumption and cold-weather/aging derating can increase required storage beyond this estimate. For more information on why DC current rises at lower voltage, see Victron Energy’s Wiring Unlimited: Current, cable resistance and voltage drop.

Check manufacturer-permitted series/parallel arrangements, usable capacity, operating-voltage range, BMS current, inverter continuous/startup capability, charging limits and installation design. Stored-energy arithmetic does not size fuses, cables or a solar recharge system.

Use the Battery Series Parallel Calculator for a separate nominal-capacity scenario, the Solar Array Planner for generation planning and the Solar Inverter Size Calculator for appliance-power assumptions.

Battery sizing questions

Does this give an exact real-world battery requirement?

No. It calculates a target under entered assumptions. Actual performance depends on equipment, operating conditions and demand patterns that the model does not fully simulate.

Will an extra margin guarantee reliable power?

No. A margin increases the target arithmetically. It does not predict outages, weather or component failure and does not replace an actual autonomy and recharge plan.

Does a valid series count mean a configuration is safe?

No. A whole-number voltage ratio is only a nominal-capacity condition. Manufacturer permission and equipment-specific installation requirements must be checked separately.
